High-Protection All-in-One Design
Meets the Demands of Harsh Environments
| System Configuration | |
| Power | DC (12V~24V)、POE (802.3af 13W)、POE+ (802.3at 25.5W) |
| Maximum working current | 0.95A(33dBm) |
| Standby current | 0.13A |
| GPIO | 2-channel photoelectric input, 2-channel relay output (standard) or 4-channel photoelectric input (optional) |
| Communication interface | RS-232, TCP/IP, WIFI (optional), One lane 485 (optional) Supports one lane of Wiegand 26, 34, 66 (optional) |
| Buzzer | The buzzer will prompt when powered on and prompt once when reading the label (can be configurated) |
| Communication protocol | TCP/HTTP/MQTT |
| API support | Android, JAVA, C#(.NET), C++(VC) |
| UHF RFID | |
| Communication protocol | EPC global C1Gen 2 (ISO 18000-6C) |
| Impinj Gen2X | support |
| Frequency | FCC 902MHz~928MHz (USA) CE 865MHz~867MHz (EU) CN 920MHz~925MHz (China) 860-960MHz (customizable) |
| Output power | 0~33dBm，1dBm(adjustable) |
| Antenna specifications | 9dBi circularly polarized antenna |
| Lobe width | Hor: 70°±5°, Ver: 70°±5° |
| Standing-wave ratio | ≤1.4 |
| Impedance | 50Ω |
| Structure Parameters | |
| Size (H * W * D) | 260x260x70mm (L x W x H) |
| Weight | 1250g |
| Radome material | ASA (anti-UV/anti-flaming) |
| Radome color | white |
| Pole diameter | Φ30-50 mm |
| Environmental parameters | |
| Working temperature | -30℃～+70℃ |
| Storage temperature | -40℃~+85℃ |
| Humidity | 5%~95% (no condensation) |
| IP rating | IP67 |
| Anti-vibration | Frequency range 5-100Hz, duration 30 minutes, acceleration 4.9m/s2 |
| Impact resistance | Endure maximum acceleration of 30m/s2, amplitude of 0.3mm, 50Hz, and duration of 2 minutes in three directions respectively |
| Anti-static | Contact discharge ± 4KV, air discharge ± 8KV |
| Electric fast transient pulse train | Power cable withstand voltage 1KV, signal cable withstand voltage 0.5KV |
| Radiated electromagnetic field immunity | Field strength 3V/m, frequency range 80-1000MHz |
| Surge immunity | Power cord: live wire to neutral wire withstand pulse voltage of 1KV Live wire to ground wire withstand pulse voltage of 2KV Zero to ground withstand pulse voltage of 2KV Signal cable: withstand pulse voltage of 1KV |
| Equipment accessories | |
| Standard accessories | Power adapter * 1, Cradle *1, GPIO plug(6 PIN)*1 |
| Optional accessories | Wi-Fi Antenna (SMA male connector)*1 |
| Note | |
| ****** | As the product line is updating from time to time, the information in this document is subject to change without notice. |
