Professional-level Product
High Performance Outcome
AnTuTu scores surpass 200,000, with performance improvements exceeding 180% compared to the previous version.
Faster processing speed and shorter response time, it can effectively handle large volumes of data.
The smoothness and multitasking capabilities of the system have been significantly enhanced to accommodate the needs of multitasking and task switching.
Right-angle and tilt-angle version available, suitable for a variety of operating scenarios
Supports standard, medium, and long-range distances, covering applications such as forklifts, inventory management, and sign for delivery, etc.
Advanced Scanning Technology Latest scan engine offers extended reading distance, broader range, and faster reading rate
| System Configuration | |
| Processor | Octa-core 2.0GHz high-performance processor |
| Operating System | Android 14.0 (GMS) |
| Memory (ROM+RAM) | 64GB + 4GB (standard) |
| SIM | Select two out of three available SIM card slots, support dual SIM and dual standby * two cards can be inserted at the same time, Nano SIM card + Nano SIM card /Nano SIM card +TF card |
| Expansion Slot | Micro SD card (up to 512GB) |
| Display Screen | 5.5-inch, resolution: 1440*720 pixels, IPS |
| Touch Screen | Industrial capacitive screen, support wet-hand operation/glove mode/multi-touch/gesture operation |
| Camera | 13MP rear camera, support auto-focus/PDAF, 5MP front camera |
| Flashlight | 1A flashlight |
| Keypad | 6 keys in total: side scan key *2, side power key *1, volume key*2, custom key*1 |
| Battery | 3.85V lithium battery, with 5000mAh, detachable, support backup battery |
| Audio | Built-in dual microphone (noise-canceling microphone) |
| Charging Method | Type-C charging and pin port charging, support 18W fast charging |
| Reminder | Vibration reminder/LED reminder/Audio reminder |
| Vibrating Motor | Built-in vibrating motor |
| Sensors | G-sensor/ Proximity sensor/Light sensor, Optional: Gyroscope/geomagnetic sensor/high- precision barometer |
| Intercom Function (Optional) | Support one-button PTT calls |
| Structure Parameter | |
| Dimension (L*W*D) | 160.7mm*74.9mm*15.4mm |
| Weight | 278g (including the battery) |
| Communication Transmission | |
| WWAN (Network Frequency) | China & Eurasian version 2G:B2/B3/B5/B8 3G:WCDMA:B1/B2/B5/B8 TD-SCDMA:B34/B39 4G:FDD-LTE:B1/B3/B5/B7/B8/B20 TDD-LTE:B34/B38/B39/B40/B41 Global version 2G:B2/B3/B5/B8 3G:WCDMA:B1/B2/B4/B5/B8 TD-SCDMA:B34/B39 4G:FDD-LTE: B1/B2/B3/B4/B5/B7/B8/B12/B17/B20/B28A/B28B TDD-LTE:B34/B38/B39/B40/B41 |
| WWAN (Data Service) | GSM/GPRS/EDGE/UMTS/HSPA/HSPA+/WCDMA/TD- SCDMA/TDD-LTE/FDD-LTE |
| WLAN Function | Wi-Fi 802.11a/b/g/n/r/ac (2.4G + 5G dual-band Wi-Fi), support fast roaming |
| Bluetooth | Bluetooth 5.0, support BLE |
| GPS | GPS/AGPS/BDS/Galileo/GLONASS/QZSS |
| Environmental Parameter | |
| Working Temperature | -20°C - 60°C *Do not charge under low temperature conditions for the safety concerns |
| Storage Temperature | -40°C - 60°C (without the battery) |
| Humidity | 0 - 95% (no moisture condensation) |
| Drop Specification | Multiple drops to concrete floor from the height of 1.5m |
| Roller Drop Specification | 1000 times of roller drops from a height of 0.5 meter |
| Ingress Protection | IP67/IP65 |
| ESD Protection | ±15KV (air discharge), ±8KV (contact discharge) |
| Scanning Engine | |
| Barcode Type | It can scan one-dimensional / two-dimensional barcodes |
| Scanning Accuracy | ≧3.33mil |
| Scanning Angle | Pitch: ±60°; Skew:±45°; Tilt:360° |
| View Angle | Horizontal:44.3°，Vertical:28.4°，Diagonal:51° |
| Motion Error Tolerance | 8m/s |
| NFC (standard) | |
| Working Frequency | 13.56 MHz |
| Reading Distance | Within 40 mm |
| Communication Protocol | ISO14443A/14443B/15693 |
| Communication Interface | |
| USB Interface | Type-C (with headset function) *1 |
| OTG Interface | Support |
| Development Support | |
| Programming Language | Java |
| Development API | iScan API (Scanning Development Kits), Device API (Device Management/Configuration Development Kits), Android Standard Interface |
| Development Tool | Eclipse/Android Studio |
| Accessories | |
| Standard Accessories | USB cable*1, back strap *1, power adapter*1, battery*1 |
| Optional Accessories | Power adapter(fast charging), 2-in-1 charging cradle, 4- slot charging cradle, multifunctional 5-slot cradle, hand strap, fanny pack, protective case, protective film |
| Note | |
| ****** | Due to irregular updates of the product line, the content is subject to change without notice. |
