Enterprise-level Smart Terminal
Sharpen Enterprise Workers’ Competitive Edges
Industry-leading Android 11.0,
Front-line Workers Enjoy Trending Smart Phone Usage Experience
5.5-inch HD Screen Provides Sufficient Room for Both Reading and Touch Control Interaction
The Screen Is Clearly Visible Even Under Direct Sunlight Outdoors.
Powerful Scan Engine, Capture Almost All One/Two Dimension(s) Barcodes Rapidly.
Equipped With a 13 Megapixels Rear Camera, It Can Take Pictures of Goods, Receipt etc. Clearly.
Read Information Quickly on All Kinds of Cards, Such As ID Cards, Membership Cards, Bus Cards,
Access Cards So That It Could Handle Verification of Different ID and Membership, or Payment Issues.
With a 5000 mAh Big Battery, It Can Easily Lasts a Whole Shift.
It Can Work Continuously Without Suspending Your Work To Replace Battery.
IP65 Protection Enables Your Workers To Work In Different Weather Conditions.
It Lowers the Rate of Product Failure, Eliminating Loss Caused by Device Downtime.
| System Configuration | |
| Processor | Octa-core 2.2GHz high-performance processor |
| Operating System | Android 13.0（AER） |
| Memory (ROM + RAM) | 64GB + 4GB (standard) |
| SIM | Two out of three SIM card slots, support dual SIM and dual standby * Two out of three SIM card slots: two cards can be held at the same time, Nano SIM card + Nano SIM card /Nano SIM card +TF card |
| Expansion Slot | Micro SD card (up to 256 GB) |
| Display Screen | 5.5-inch, resolution: 1440*720 pixels IPS HD screen |
| Touch Screen | Industrial capacitive screen, support wet-hand operation/glove mode/multi-touch/gesture operation |
| Camera | 13 megapixels of rear camera, 5 megapixels of front camera, support auto-focusing |
| Flashlight | 1A flashlight |
| Keypad | 5 keypads in total: scan key *2, power key *1, ±volume key *2 |
| Battery | 4.35V lithium battery, with 5000 mAh, detachable, with backup battery *Execution standard: GB31241-2014 |
| Audio | Built-in microphone |
| Charging Method | Type-C charging , support 9V/2A, 5V/3A fast charging |
| Reminder | High-power speaker/Vibration reminder/LED reminder |
| Vibrating Motor | Built-in vibrating motor |
| Sensors | G-sensor/ Proximity sensor/Light sensor |
| Intercom Function (Optional) | Support one-button PTT calls |
| Structure Parameter | |
| Dimension (L*W*D) | 162.2mm*78.5mm*15mm |
| Weight | 258g (including the battery) |
| Communication Transmission | |
| WWAN (Network Frequency) |
Chinese version: 2G: B2/B3/B5/B8 3G: WCDMA: B1/B5/B8, TD-SCDMA: B34/B39 4G: FDD-LTE: B1/B3/B4/ B5/B7/B8, TDD-LTE: B34/B38/B39/B40/B41 |
| WWAN (Data Service) |
GPRS/EDGE 3G/GSDPA 42.2M/HSUPA 11.5M/LTE-DL 150 Mbps/UL 50 Mbps |
| WLAN Function | Wi-Fi 802.11 /a/b/g/n/ac/d/e/h/i/j/k/r/v/w (2.4G + 5G dual-band Wi-Fi) |
| Bluetooth | Bluetooth 5.0, support BLE |
| GPS | GPS/AGPS/ BDS/Galileo/GLONASS/QZSS |
| Environmental Parameter | |
| Working Temperature |
-20℃ - 50℃ *Do not charge under low temperature conditions for the safety concerns |
| Storage Temperature |
-40℃ - 70℃ |
| Humidity | 0 - 95% (no moisture condensation) |
| Drop Specification | Multiple drops to concrete floor from the height of 1.5m |
| Environmental Parameter | 500 times circulation (1000 times) of roller drops from a height of 0.5 meter |
| Ingress Protection | IP65 |
| ESD Protection | ±15KV (air discharge), ±8KV (contact discharge) |
| Scanning Engine | |
| Barcode Type | It can scan one-dimensional / two--dimensional barcodes |
| Scanning Accuracy | ≧3.33mil |
| Scanning Angle | Pitch: ±60°； Skew：±45°； Tilt：360° |
| View Angle | Horizontal：44.3°，Vertical：28.4°，Diagonal：51° |
| Motion Error Tolerance | 8m/s |
| NFC (Optional) | |
| Working Frequency | 13.56 MHz |
| Reading Distance | Within 35 mm |
| Communication Protocol | ISO14443A/14443B/15693 |
| Communication Interface | |
| USB Interface | Type-C (with headset function) *1 |
| OTG Interface | Support |
| Development Support | |
| Programming Language | Java |
| Development API | iScan API (Scanning Development Kits), Device API (Device Management/Configuration Development Kits), Android Standard Interface |
| Development Tool | Eclipse/Android Studio |
| Accessories | |
| Accessories (standard) | USB cable*1, power adapter*1, hand strap*1 |
| Accessories (optional) | 4-slot charging cradle, fanny pack, protective film, protective case |
| Note | |
| 1 | Due to irregular updates of the product line, the content is subject to change without notice. |
