AI-powered
Enables highly efficient scanning
Utilizes white electric light source + red and blue surface light sources to handle complex situations like insufficient brightness and surface glare, improving scanning capture rate.
IP67 protection level + strict anti-drop tests, rugged and durable design provides stable and continuous operation, reduces probability of device damage, extends service life.
| Performance Parameter | |
| Image sensor | 1280 * 800 pixels, global exposure |
| Light Source | White point light source+ red & blue surface light source |
| Scanning Performance | |
| Aiming | laser |
| Scanning performance | |
| Reading accuracy | ≥3.33mil |
| Scanning angle | Pitch: ± 72.5 °; Skew: ± 60 °; Tilt: 360 ° |
| Field of view angle | Horizontal: 44.3 °, Vertical: 28.4 °, Diagonal: 51 ° |
| Motion tolerance | 13mil UPC 2m/s (supports a maximum of 8m/s in high motion fault-tolerant mode) |
| Minimum Reading Contrast | 6% |
| Physical parameters | |
| Size (H * W * D) | 180.3mm*87.3mm*69.3mm |
| Weight | Wired: 139.5g Wireless: 257.0g |
| Working voltage | Wired: 5V ± 0.5V Wireless: 3.5~4.2V |
| Current value | Wired: 190mA (typical value), 460mA (maximum value) Wireless: 222mA (typical), 575mA (maximum) |
| Interface | USB-HID，USB-CDC，RS232 |
| Notification | Speaker+LED+vibration motor |
| Housing material | PC+GF+ABS |
| Environmental parameters | |
| working temperature | 0℃~50℃ |
| Storage temperature | -20℃~70℃ |
| Humidity | 5% to 95% (no condensation) |
| Ingress Protection | IP67 |
| Drop specification | Multiple drops to cement floor at 2 meters height |
| Ambient light | 0Lux~100000Lux |
| Static protection | ± 15KV (air discharge), ± 8KV (contact discharge) |
| Decoding range | |
| 3.33mil Code128 | XD (ultra-high density):0cm~2cm HD (High Density):2.5cm~9.5cm SR (Standard Distance):9.0cm~15cm |
| 10.83mil Code128 | XD (ultra-high density):0cm~4.5cm HD (High Density):0cm~16.5cm SR (Standard Distance):2.0cm~41.0cm |
| 5.83mil QR Code | XD (ultra-high density):0cm~2.5cm HD (High Density):2.5cm~8.0cm SR (Standard Distance):/ |
| 20.83mil QR Code | XD (ultra-high density):0.5cm~6.0cm HD (High Density):0.5cm~19cm SR (Standard Distance):0.5cm~51cm |
| Code recognition system | |
| 1D | Codabar，Code 11，Code 128，Code 32，Code 39，Code 93，EAN 13，EAN 8，UPC-A，UPC-E，IATA 2 of 5，Interleaved 2 of 5，Matrix 2 of 5，Straight 2 of 5，MSI/PIessey，GS1 DataBar， etc |
| 2D | Aztec，Data Matrix，Micro PDF 417，PDF 417，QR，Micro QR，Grid Matrix etc |
| Wireless transmission performance BT (wireless version only) | |
| Bluetooth | Bluetooth 5.0 |
| Frequency band | Frequency band |
| Transmission distance | up to 70m in an open space |
| Communication mode | Base HID/Base CDC/Base RS232 |
| Scan configuration (wireless version only) | |
| Battery capacity | 3200mAh, detachable |
| Charging time | 3 Hours (5V/2A) |
| Working hours | ≥12h |
| Number of scans | Each charge can suport over 100000 times |
| Related regulations | |
| Electrical safety | IEC 60950 |
| Environmental parameters | RoHS directive 2011/65/EU，GB/T 26572 |
| LED safety | IEC 62471:2006 |
| EMI/RFI | FCC Part 15 Class B，EN 55032:2015，EN 55035:2017 |
| Accessories | |
| Standard accessories | Wired: data cable*1, user manual*1 Wireless: base * 1, adapter * 1, data cable * 1, user manual * 1 |
| Optional Accessories | Serial port cable, cradle |
| Note | |
| ****** | As the product line is updating from time to time, the information in this document is subject to change without notice. |
