High-efficient Mobile Computer
Equipped with 4-inch (800*480 resolution) super definition screen and full digital keyboard,
achieve the best experience of large screen and single handed operation,With the brand new
design ergonomic scanning angle, effectively reduce wrist motions and fatigue, easy to scan
and verify.
Dual-band Wi-Fi technology, enable free switch and transmission between two channel frequencies,
and make the signal stronger and more stable. Seamless network selection and connection according
to needs with 4G wireless communication supported by all network operators helps to realize more
efficient business data connection and communication,Bluetooth 5.0 transmission technology, the
transmission speed is increased by 2 times,the effective working distance can reach 300 meters,and
the transmission distance is faster and farther.
The use of low-energy-consuming chipset and optimized system result in more efficient and less energy-consuming operations,
Fast recharging technology is adopted to shorten the recharging time and further extend the battery life.
Customization capability of specific enterprise special scenarios:
Wi-Fi change strategy custom, scan custom, camera collection efficiency custom, RFID performance custom capability,
PSAM custom capability， keys and shell custom capability, all kinds of modules integration development capability…….
| System Configuration | |
| Processor | Basic models: Quad-core 1.3 GHz Upgrade models: Octa-core 2.0 GHz |
| Operating system | Basic models: Android 6.0 Upgrade models: Android 10.0 |
| Memory (ROM+RAM) | Basic models: 16GB+2GB Upgrade models: 16GB+2GB，64GB+4GB(optional） |
| SIM | Basic models: Single SIM card Upgrade models: Single SIM card （ESIM optional） |
| Expansion slot | Basic models: Micro SD卡（Up to 32GB） Upgrade models: Micro SD card, up to 256 GB |
| Display screen | 4-inch, resolution: 800*480 pixel |
| Touch screen | Industrial capacitive screen, supporting two-point touch + gesture operation |
| Camera | Basic models: 8 MP autofocus camera in the back side, LED flash Upgrade models: 8 MP autofocus camera in the back side (13 MP optional), LED flash |
| Flashlight | 800mA flashlight |
| Keyboard | Front key*20, side scan key*2, side custom key*2 (internal light-transmitting industrial IMD keyboard) |
| Battery | Lithium battery 3.8V, 4000mAh, removable *Executive standard: GB31241-2014 |
| Audio | Built-in microphone |
| Charging | Basic models: Type-C charging and pin port charging Upgrade models: Type-C charging and pin port charging, 18W fast charging |
| Prompts | High-power speaker/vibration reminder/LED reminder/audio reminder |
| Vibrating motor | Built-in vibrating motor |
| Sensor | Gravity sensor (G-sensor) / proximity sensor / light sensor / geomagnetic sensor |
| Intercom function (optional) | Supporting one-button PTT calls |
| Structure parameters | |
| Dimension (LxWxD) | 159mm*71mm*20mm 160mm*71mm*36.5mm |
| Weight | 262g 388g |
| Communication transmission | |
| Wireless wide area network (Network frequency) |
Basic models: 2G：B2/B3/B8 3G：WCDMA：B1/B2，CDMA&EVDO：BC0，TD-SCDMA：B34/B39 4G：FDD-LTE：B1/B3/B7/B8/B20，TDD-LTE：B38/B39/B40/B41 Upgrade models: Asia & Europe： 2G：B2/B3/B5/B8 3G：WCDMA：B1/B5/B8，CDMA BC0，TD-SCDMA：B34/B39 4G：FDD-LTE：B1/B3/B5/B7/B8/B20，TDD-LTE：B34/B38/B39/B40/B41 America： 2G：B2/B3/B5 3G：B1/B2/B4/B5，CDMA&EVDO：BC0/BC1 (America) 4G：B1/B2/B3/B4/B5/B7/B12/B17/B28A/B28B/B41 |
| Wireless wide area network (Data service) |
GSM/GPRS/EDGE/CDMA/UMTS/HSPA/HSPA+/EVDO/WCDMA/TD-SCDMA/TDD-LTE/FDD-LTE |
| WLAN | Basic models: Wi-Fi 802.11a/b/g/n（2.4G+5G dual-band Wi-Fi） Upgrade models: Wi-Fi 802.11a/b/g/n/r/ac（2.4G+5G dual-band Wi-Fi） ,Wi-Fi 5G PA |
| Bluetooth | Basic models: Bluetooth 4.0 Upgrade models: Bluetooth 5.0 |
| GPS | Basic models: GPS/AGPS/Beidou/GLONASS Upgrade models: GPS/AGPS/Beidou/Galileo/GLONASS/QZSS |
| Operating Environment | |
| Working temperature | -20℃~60℃ *For your safety, please do not charge in a low temperature environment |
| Storage temperature | -40℃~60℃（Without battery） |
| Humidity | 0%～95% (no condensation) |
| Drop specification | 1.5m concrete floor dropped several times |
| Protection level | IP65 |
| Electrostatic protection | ±15KV (air discharge), ±8KV (contact discharge) |
| Scan engine | |
| Barcode | Support 1D/2D scanning engine |
| Scanning accuracy | ≥3.33mil |
| Scanning angle | Tilt ±60°, deflection ±60°, rotation 360° |
| Angular Field of View | Horizontal: 44.3°; Vertical: 28.4°; Diagonal: 51° |
| Motion tolerance | 8m/s |
| NFC (Optional) | |
| Frequency | 13.56MHz |
| Reading distance | Within 10mm |
| Communication protocol | ISO14443A/14443B/15693 |
| Input/output Interface | |
| USB interface | Type-C (with earphone function) *1 |
| OTG | Supporting |
| Development support | |
| Development language | Java |
| API | iScan API (Scan Development Kit), Device API (Device Management/Configuration Development Kit), Android standard interface |
| Development tool | Eclipse/Android Studio |
| Accessories | |
| Standard accessories | USB cable*1, power adaptor*1, charging cable*1, lithium battery*1, hand strap*1, wrist strap*1 |
| Optional accessories | charging cable，single cradle、device 4-slot charging cradle，battery 4-slot charging cradle，protective film，protective case，waist bag，extended back clip |
| Note | |
| 1 | Due to irregular updates of the product line, the content is subject to change without notice. |
